EU/Japanese Wheel Hubs
Wheel Hub
R 15.09
| Brand | MERCEDES |
|---|---|
| Rastgar No. | R 15.09 |
| OEM Number | 9723300125 |
| Cross Reference | 9703300144 , 9703340344 , 9703340345 , 9723300225 , 9723300325 , 9723300425 , 9723300525 , 9723340201 |
| Application | ATEGO / ACTROS / AXOR |
| Front / Rear | Front |
| Material | EN-GJS-600-3 |
| ABS | Compatible |
Dimension Reference
| ABS | A [mm] | B [mm] | C [mm] | D [mm] | E [mm] |
|---|---|---|---|---|---|
| ✓ | UNITISED BEARING 108 | UNITISED BEARING 108 | M14 x 1.5 | 113 | 146 |
Technical Specifications
| Outer Diameter | PCD | No. of Holes | Inner Bearing | Outer Bearing | Assembly Height | Surface Coating |
|---|---|---|---|---|---|---|
| 146 | 120 | 10 | UNITISED BEARING 108 | UNITISED BEARING 108 | 113 | BLACK AIR DRYING |
Comparison Numbers
| Type | Ref. No. |
|---|---|
| OEM / Cross Ref. | 9723300125 |
| Cross Ref. | 9723300225 |
| Cross Ref. | 9723300525 |
| Cross Ref. | 9723340201 |
| Cross Ref. | 9723300425 |
| Cross Ref. | 9723300325 |
| Cross Ref. | 9703300144 |
| Cross Ref. | 9703340345 |
| Cross Ref. | 9703340344 |
| Customer Ref. | Complete Hub Technologies: R 15.09 |
| Customer Ref. | Fersa Bearings S.A.: 41310035101000 |
| Customer Ref. | Fersa Bearings S.A.: F 400011 |
| Customer Ref. | Universal Components U.K Limited: MRHB0010 |
| Product Ref. | R 15.09 G00107|Wheel Hub Assembly |
